ASRock B550 Phantom Gaming 4 AM4 ATX Motherboard DDR4
ASRock
ASRock B550 Phantom Gaming 4 AM4 ATX Motherboard DDR4
The ASRock B550 Phantom Gaming 4 is an AM4 ATX motherboard for Ryzen 3000 through 5000 series processors, built for gamers and overclockers who want solid power delivery, PCIe 4.0 storage support, and integrated audio tuning. It balances gaming-focused features with stability for both stock and overclocked systems.
Why this product
PCIe 4.0 for next-gen storage
One Hyper M.2 slot runs at full PCIe Gen4x4 speed, enabling modern NVMe drives to reach their rated performance without bandwidth compromise.
8-phase power delivery for overclocking
Premium 50A power chokes rated three times better than traditional designs deliver stable Vcore voltage and lower temperatures under load.
Nahimic audio with sound tracking
7.1 HD audio codec paired with directional sound positioning on a 360° radar helps you pinpoint in-game audio cues.
Dual GPU support via CrossFireX
Two PCIe x16 slots allow AMD graphics cards to work in tandem for higher frame rates in supported titles.
Addressable RGB headers for lighting sync
Onboard RGB and addressable RGB headers connect strips, fans and coolers; Polychrome RGB Sync matches effects across certified accessories.
- ChipsetAMD B550
- CPU SocketAMD AM4
- Form FactorATX
- Memory Slots4 x DDR4 DIMM
- Max Memory128 GB
- PCIe 4.0 M.2 Slots1 x Hyper M.2
- Rear USB 3.2 Gen16 ports
- SKUASR-1910
- EAN4710483931499
- Fits all Ryzen 3000, 4000 G-Series and 5000 series processors in AM4 socket, including non-overclocked variants.
- Supports up to 128 GB of DDR4 memory across four DIMM slots, with rated speeds of DDR4-4733 and above via overclocking.
- Provides one HDMI output for discrete GPU or APU graphics; does not include DisplayPort.
- AMD CrossFireX requires two AMD graphics cards in the x16 slots; does not support NVIDIA SLI or mixing GPU brands.
- No Wi-Fi onboard; the M.2 Key E slot is reserved for optional WiFi modules, not NVMe storage.
Best for
- Ryzen 5000 builders on a mid-range budget
- Overclockers seeking stable power delivery and low thermals
- Gamers who value directional audio cues and RGB lighting sync
- Multi-GPU AMD setups via CrossFireX
- Builds mixing PCIe 4.0 NVMe with legacy SATA storage
Trade-offs
- Wireless users: No integrated Wi-Fi; requires a separate PCIe card or USB adapter.
- NVIDIA users: Supports only AMD CrossFireX for multi-GPU; no SLI support.
- DisplayPort-only setups: HDMI is the sole video output; no DisplayPort connector.
- Minimal storage builders: Only one PCIe 4.0 slot for M.2; additional storage depends on six SATA ports.
Phantom Gaming is designed by gamers and for gamers! Underneath its relentless appearance lie plentiful gaming oriented features and excellent gaming capabilities. It's all about bringing a new gaming experience to gamers!
Whether you are using headphones, a headset, external or internal speakers, via USB, Wi-Fi, analog output or even HDMI, Nahimic Audio offers you the most engaging listening experience, vibrant and rich with details. The Sound Tracker is a visual indicator that points out the directions from which predominant sounds are coming. Each sound is properly positioned in 360° on a radar for a full immersion during the game.
Featuring sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well. Compared to traditional chokes, ASRock's premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the motherboard. 2 ounce copper inner layers that provide stable signal traces and power shapes! Delivering lower temperature and higher energy efficiency for overclocking, it's able to support the latest DDR4 memory modules with most extreme memory performance!
This motherboard features onboard RGB headers and an addressable RGB header that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects.
General
| Brand | ASRock |
|---|---|
| Model | B550 Phantom Gaming 4 |
| Chipset | AMD B550 |
| Form Factor | ATX |
Processor & Memory
| CPU Socket | AMD AM4 |
|---|---|
| Supported Processors | Ryzen 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series |
| Memory Slots | 4 x DDR4 DIMM |
| Maximum Memory | 128 GB |
| Memory Speed (OC) | DDR4-4733+ |
Storage & Expansion
| SATA Ports | 6 x SATA3 |
|---|---|
| M.2 PCIe 4.0 | 1 x Hyper M.2 (PCIe Gen4x4) |
| M.2 PCIe 3.0 | 1 x M.2 (PCIe Gen3x2 & SATA3) |
| M.2 WiFi Slot | 1 x M.2 Key E |
| PCIe Slots | 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1 |
| Multi-GPU Support | AMD CrossFireX™ |
Connectivity & Audio
| USB 3.2 Gen1 | 8 ports (2 Front, 6 Rear) |
|---|---|
| LAN | Gigabit (Realtek RTL8111H) |
| Video Output | 1 x HDMI |
| Audio Codec | Realtek ALC1220/ALC1200 |
| Audio Channels | 7.1 HD with Nahimic Audio |
| RGB Headers | Standard RGB + Addressable RGB (Polychrome Sync) |
Power & PCB
| Power Phases | 8-phase with Digi Power |
|---|---|
| Power Chokes | Premium 50A chokes |
| PCB Copper | 2 oz copper with solid capacitor design |
