Gigabyte GC-WFAX210 WiFi 6E AX210 PCIe Card - 2400Mbps, BT 5.2
GIGABYTE
Gigabyte GC-WFAX210 WiFi 6E AX210 PCIe Card - 2400Mbps, BT 5.2
The Gigabyte GC-WFAX210 is a PCIe 4.0 expansion card that adds WiFi 6E and Bluetooth 5.2 connectivity to desktop computers. It suits users upgrading older systems to access the 6GHz band and faster wireless speeds without replacing the motherboard.
Why this product
WiFi 6E with dedicated 6GHz band
Access a new spectrum band designed to reduce congestion and deliver faster, more stable connections than traditional 2.4GHz and 5GHz alone.
Up to 2400 Mbps wireless speed
Supports dual-stream transmission across all three bands with MU-MIMO technology for improved multi-device performance.
PCIe 4.0 interface
Uses the latest PCIe generation for twice the bandwidth of PCIe 3.0, future-proofing the connection.
Bluetooth 5.2 included
Adds wireless connectivity for peripherals and mobile devices alongside WiFi capabilities.
EZ-Plug antenna design
Single integrated connector simplifies installation without requiring multiple antenna plugs.
- WiFi standardIEEE 802.11ax (WiFi 6E)
- Max wireless speedUp to 2400 Mbps
- Frequency bands2.4GHz / 5GHz / 6GHz (Tri-Band)
- Bluetooth5.2
- InterfacePCIe 4.0 x1
- Antenna2Tx2R directional Ultra-high gain
- SKUGIG-1331
- EAN4719331879631
- Works with any desktop PC with a free PCIe x1 slot.
- Supports Windows, Linux and other operating systems with appropriate drivers.
- WiFi 6E and 6GHz band support vary by country; check local regulations before purchase.
- Some WiFi Alliance certifications are OS-dependent and may require manufacturer support.
Best for
- Desktop users upgrading from older WiFi standards without replacing the motherboard.
- Homes or offices with spectrum congestion from many WiFi devices.
- Users needing both high-speed WiFi and Bluetooth 5.2 connectivity.
- Systems with PCIe 4.0 support looking to maximize bandwidth for wireless communication.
Trade-offs
- Laptops or systems without an available PCIe slot.
- Users in regions where WiFi 6E or 6GHz spectrum is not yet approved.
- Systems requiring internal antennas; this card requires external antenna connection.
GC-WFAX210 is an exclusive PCIe expansion card that offers support for the latest High quality 802.11ax 80MHz Tri-Band WIFI and BLUETOOTH 5.2 connectivity.
Spectrum congestion is huge problem in current WIFI environment nowadays because too many devices all use existing 2.4GHz and 5GHz spectrum, and it cause unreliable connection and slower speed. WIFI 6E is extended standard to WIFI 6, and it use dedicated 6GHz band that it provides not only brand new frequency to transfer data, but also spacious spectrum for future more devices. With WIFI 6E, users can enjoy faster connection and stronger signal than before.
PCIe 4.0 Interface
GC-WFAX210 features PCIe 4.0 interface which are expected to experience twice bandwidth than PCIe 3.0 devices.
WIFI EZ-Plug
The WIFI EZ-Plug design integrates Wi-Fi antenna plugs into one adapter, EZ to install.
Directional Ultra-high Gain Antenna
Boost your signal strength with GIGABYTE's Ultra-high gain Antenna, featuring smart antenna technology for optimized Wi-Fi signal transmission.
Wireless Alliance*: Wi-Fi CERTIFIED 6*, CERTIFIED* a/b/g/n/ac WMM*, WMM*-Power Save, WPA3, PMF*, Wi-Fi Direct*, WIFI Agile Multiband.
* Support of Wi-Fi Alliance certifications is OS-dependent.
IEEE WLAN Standard: IEEE 802.11-2016 and select amendments (selected feature coverage) IEEE 802.11a, b, d ,e ,g ,h ,I ,k , n ,r ,u ,v ,w ,ac ,ax ; Fine Timing Measurement based on 802.11-2016, Wi-Fi Location R2 (802.11az) HW readiness* * IEEE 802.11az hardware readiness per expected Wi-Fi Location R2 feature support and based on draft 2.1 of the IEEE 802.11az amendment and is subject to change.
* Wi-Fi 6E and its 6GHz carrier frequency support may vary by country.
Security Features*: Security Methods - WPA2* ; WPA3 * Authentication Protocols - 802.1X EAP-TLS,EAP-TTLS/MSCHAPv2, PEAPv0 –MSCHAPv2 (EAP-SIM, EAP-AKA, EAP-AKA') * Some security solutions may not be supported by your device operating system and/or by your device manufacturer or may require additional hardware (e.g UICC_SIM card).Check with your device manufacturer for details on availability.
* Product specifications and product appearance may differ from country to country. We recommend that you check with your local dealers for the specifications and appearance of the products available in your country. Colors of products may not be perfectly accurate due to variations caused by photographic variables and monitor settings so it may vary from images shown on this site.
Networking
| Brand | Gigabyte |
|---|---|
| Model | GC-WFAX210 |
| Wireless module | Intel WiFi 6E AX210 |
| WiFi standard | IEEE 802.11ax compliant |
| IEEE WLAN Standard | IEEE 802.11a, b, d, e, g, h, I, k, n, r, u, v, w, ac, ax; IEEE 802.11-2016 and select amendments |
| Frequency bands | 2.4GHz / 5GHz / 6GHz (Tri-Band) |
| Bluetooth | Fully qualified BLUETOOTH 5.2 |
| MIMO | MU-MIMO TX/RX |
Performance
| Max wireless speed | Up to 2400 Mbps |
|---|---|
| Wi-Fi Location | Wi-Fi Location R2 (802.11az) HW readiness |
Ports & power
| Interface | PCIe 4.0 x1 |
|---|---|
| Antenna connector | WIFI EZ-Plug (integrated antenna plugs) |
Physical
| Antenna | 2Tx2R directional Ultra-high gain Antenna |
|---|---|
| Security | WPA2, WPA3; 802.1X EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0–MSCHAPv2 (EAP-SIM, EAP-AKA, EAP-AKA') |
| Wi-Fi Alliance Certifications | Wi-Fi CERTIFIED 6, CERTIFIED a/b/g/n/ac WMM, WMM-Power Save, WPA3, PMF, Wi-Fi Direct, WIFI Agile Multiband |
