Gigabyte X870E AORUS Elite X3D AM5 ATX Motherboard Wi-Fi 7
GIGABYTE
Gigabyte X870E AORUS Elite X3D AM5 ATX Motherboard Wi-Fi 7
The Gigabyte X870E AORUS Elite X3D is an AM5 ATX motherboard built for enthusiasts who want to extract every frame from AMD Ryzen X3D processors without manual tuning. Its proprietary X3D Turbo Mode 2.0 uses a built-in AI model and dedicated hardware circuits to dynamically optimise X3D processor parameters in real time, and a one-click activation system extends that same ease to DDR5 memory overclocking. Connectivity is covered by 5GbE wired LAN and Wi-Fi 7, making it well suited to high-throughput home networks and streaming rigs alike.
Why this product
X3D Turbo Mode 2.0 for real-time AI optimisation
A built-in AI model and dedicated hardware circuits dynamically tune Ryzen X3D processor parameters in real time across two selectable profiles — Extreme Gaming Mode and Max Performance Mode.
DDR5 overclocking up to 9000 MT/s
Four DDR5 DIMM slots support speeds from standard 4800 MT/s up to 9000 MT/s (O.C.), with AMD EXPO module support and advanced PCB shielding to keep memory signals clean.
Four M.2 slots including two PCIe 5.0
Storage expansion covers two PCIe 5.0 x4 M.2 slots and two PCIe 4.0 M.2 slots, each fitted with the M.2 EZ-Latch Click or Plus screwless retention system and dedicated thermal guards.
16+2+2 phase digital twin VRM
The digital twin power delivery architecture uses a 16+2+2 phase design fed by dual 8+8 pin CPU connectors, supported by a VRM Thermal Armor Advanced heatsink and a 7 W/mk thermal pad.
Wi-Fi 7 and 5GbE LAN on board
Wireless connectivity is handled by Wi-Fi 7 with a directional ultra-high gain antenna, while the wired port delivers 5GbE throughput — both supported by DriverBIOS pre-installed Wi-Fi drivers for out-of-box access.
Dual USB4 Type-C with DisplayPort Alt mode
The rear panel provides two USB4 Type-C ports with DP-Alt mode alongside HDMI output, and the front-panel header supports Quick Charge USB at up to 65 W.
- SocketAMD AM5
- ChipsetAMD X870E
- Form FactorATX
- Memory4 x DDR5 DIMM (Dual Channel), up to 9000 MT/s O.C.
- Primary PCIe SlotPCIe 5.0 x16 (PCIe UD Slot X)
- M.2 Slots4 total (2 x PCIe 5.0, 2 x PCIe 4.0)
- Networking5GbE LAN + Wi-Fi 7
- USB42 x USB4 Type-C with DP-Alt
- SKUGIG-1870
- EAN4719331876470
- Fits AMD Socket AM5 — compatible with AMD Ryzen 9000, 8000 and 7000 Series processors (verify specific CPU against GIGABYTE's current support list).
- ATX form factor — fits standard ATX mid-tower and full-tower cases.
- Accepts DDR5 DIMMs only — four slots in dual-channel configuration with AMD EXPO support.
- X3D Turbo Mode 2.0 benefits apply specifically to AMD Ryzen X3D processors; standard Ryzen models will not use X3D-specific optimisations.
- Does not support DDR4 memory — the platform is DDR5 only.
- Not compatible with Intel processors or any non-AM5 AMD socket (AM4, TR4, etc.).
Best for
- AMD Ryzen X3D gaming builds where AI-driven per-game CPU tuning and one-click profile switching deliver measurable frame-rate gains without manual overclocking.
- High-bandwidth storage setups that need multiple fast drives — two PCIe 5.0 M.2 slots and two PCIe 4.0 M.2 slots accommodate large NVMe arrays alongside four SATA 6 Gb/s ports.
- Content creators and streamers who benefit from 5GbE wired LAN, Wi-Fi 7, and dual USB4 Type-C ports with DP-Alt for high-speed peripherals and multiple display outputs.
- ARGB lighting builds where three ARGB headers and one RGB header give enough bandwidth to run a full suite of fans, strips and coolers from a single board.
- Builders who dislike fiddly installation steps, as screwless M.2 EZ-Latch retention, WIFI EZ-Plug antenna design and an integrated IO shield reduce assembly time.
Trade-offs
- Intel platform builds — it is an AM5 socket board and is physically and electrically incompatible with any Intel processor.
- DDR4 memory owners — the board accepts DDR5 only; existing DDR4 kits cannot be used.
- Mini-ITX or Micro-ATX cases — the ATX form factor will not physically fit smaller chassis designed for those standards.
- Budget-focused builds that do not need X870E chipset features such as PCIe 5.0 on both the primary slot and M.2, or dual USB4 — a lower-tier chipset board would cover basic needs at lower cost.
Incredible X3D performance unleashed by AI.
X3D Turbo Mode 2.0 delivers enhanced gaming and multitasking performance over the first generation. Built-in AI model and hardware circuits dynamically optimize X3D processor parameters in real-time, significantly boosting Ryzen™ X3D performance. Through GIGABYTE's innovative X3D Turbo Mode 2.0 technology, users can enjoy a smoother gaming experience. Faster, fiercer, more precise with a single click.
X3D Turbo Mode 2.0 offers two distinct modes — Extreme Gaming Mode & Max Performance Mode — allowing users to freely switch between them based on their usage scenario to achieve optimal performance.
Unleash Ultimate Performance with One-Click Activation. With just a single click, unleash the full potential of CPU & DDR5 memory, instantly boosting your gaming and work efficiency.
X3D series gaming motherboards boost DDR5 memory performance and offer top-notch compatibility using various advanced methods.
Advanced shielding inside the PCB keeps your memory signals clean and interference-free.
General
| Brand | GIGABYTE |
|---|---|
| Form Factor | ATX |
| Socket | AMD AM5 |
| Chipset | AMD X870E |
| CPU Compatibility | AMD Ryzen 9000 / 8000 / 7000 Series |
| PCB | 8-Layer, 2X Copper |
| IO Shield | Integrated |
Memory & Storage
| Memory Type | DDR5 |
|---|---|
| Memory Slots | 4 x DDR5 DIMM (Dual Channel) |
| Memory Speed (O.C.) | Up to 9000 MT/s |
| Memory Standards | AMD EXPO supported |
| M.2 Slots | 2 x PCIe 5.0 x4, 2 x PCIe 4.0 |
| SATA Ports | 4 x SATA 6 Gb/s |
| RAID | RAID 0, 1, 5, 10 (NVMe) |
Expansion & Connectivity
| PCIe x16 Slot | 1 x PCIe 5.0 x16 (PCIe UD Slot X) |
|---|---|
| Additional PCIe Slots | 1 x PCIe 4.0 x4, 1 x PCIe 3.0 x2 |
| LAN | 5GbE |
| Wireless | Wi-Fi 7 with directional ultra-high gain antenna |
| Rear USB | Dual USB4 Type-C with DP-Alt mode |
| Front USB | Quick Charge USB 65W |
| Video Output | HDMI, USB4 Type-C DP-Alt (x2) |
Power, Audio & Lighting
| VRM Phases | 16+2+2 (Digital twin) |
|---|---|
| CPU Power Connectors | 8+8 pin |
| ATX Power Connector | 24 pin |
| Audio | 8-channel HD Audio with high-end audio capacitors |
| BIOS | 512 Mb SPI Flash ROM UEFI AMI BIOS |
| RGB Headers | 1 x RGB, 3 x ARGB |
| LED Headers Total | 4 |
