Intel Core i7-14700F 20-Core LGA1700 Processor - 65W, No iGPU
Intel
Intel Core i7-14700F 20-Core LGA1700 Processor - 65W, No iGPU
The Intel Core i7-14700F 20-Core LGA1700 Processor is built for PC builders who need strong multi-threaded performance for gaming, content creation, and productivity without paying for integrated graphics they won't use. Its Hybrid Core Architecture pairs eight Performance-cores for demanding workloads with twelve Efficient-cores for background tasks, covering both high-load and everyday use in a single 65W base TDP package.
Why this product
20 cores, 28 threads for heavy workloads
Eight Performance-cores clock up to 5.4 GHz via Turbo Boost Max 3.0, while twelve Efficient-cores handle background tasks, giving the system 28 threads total for rendering, encoding, and multitasking.
Intel Thread Director optimises every workload
Built directly into the core hardware, Intel Thread Director works with the operating system to assign each thread to the right core type at the right time, without manual tuning.
PCIe 5.0 and PCIe 4.0 support
Up to 20 PCIe lanes are available — 16 at PCIe 5.0 and 4 at PCIe 4.0 — supporting the latest graphics cards and NVMe storage devices.
DDR5 and DDR4 memory compatibility
It supports up to 192 GB of dual-channel memory, accepting either DDR5 at up to 5600 MT/s or DDR4 at up to 3200 MT/s, including ECC configurations.
Cooler included in the box
An Intel Laminar RM1 cooler ships with the processor, so builders do not need to budget for a separate cooler unless they prefer an aftermarket option.
Fits Intel 600 and 700 series motherboards
The LGA 1700 socket is compatible with both Intel 600 Series and Intel 700 Series chipsets, giving builders flexibility across a wide range of available motherboards.
- Cores / Threads20 cores / 28 threads
- Base Clock (P-core)2.1 GHz
- Max Turbo Frequency5.4 GHz
- TDP (Base Power)65 W
- SocketLGA 1700 (FCLGA1700)
- Max Memory192 GB DDR5 / DDR4
- PCIe SupportPCIe 5.0 + PCIe 4.0 (20 lanes)
- Included CoolerIntel Laminar RM1
- SKUINT-2071
- EAN5032037547680
- Fits LGA 1700 socket motherboards — compatible with Intel 700 Series and Intel 600 Series chipsets.
- Works with DDR5 memory at up to 5600 MT/s in dual-channel configuration.
- Works with DDR4 memory at up to 3200 MT/s in dual-channel configuration.
- Supports ECC memory for workstations or applications that require error-correcting memory.
- Single-socket (1S) scalability only — not suited to multi-socket server or workstation builds.
- Does not have integrated graphics — a dedicated discrete graphics card is required to obtain any display output.
Best for
- Gamers pairing it with a dedicated GPU — the high single-core boost frequency and 20-core design handle modern titles and background streaming without bottlenecking a discrete graphics card.
- Content creators and video editors — 28 threads and 33 MB of cache make it capable of sustained rendering and encoding workloads.
- Builders upgrading an existing 600-series board — LGA 1700 compatibility means it can drop into many current-generation motherboards without a platform change.
- Workstation users needing ECC memory — DDR5 and DDR4 ECC support is confirmed, which is useful for data-sensitive or professional applications.
- Budget-conscious builders skipping integrated graphics — the F-suffix variant trades the unused iGPU for a typically lower price point, making sense when a discrete GPU is already planned.
Trade-offs
- Builds without a discrete GPU — this processor has no integrated graphics, so it cannot drive a display on its own.
- Multi-socket server builds — scalability is rated 1S Only, meaning it is not designed for dual- or quad-socket configurations.
- Ultra-low-power or fanless systems — maximum turbo power reaches 219 W, which requires adequate case airflow and cooling headroom beyond what passive or very compact setups typically provide.
- Platform shoppers wanting AM5 or other sockets — it is designed exclusively for the LGA 1700 socket and will not fit AMD or other Intel socket generations.
Power up your productivity, gaming, and content creation with the Intel Core i7-14700F 2.1 GHz 20-Core LGA 1700 Processor. Built with the Intel 7 process, this 14th generation desktop processor delivers improved power efficiency with a total of 20 cores while fitting the LGA 1700 socket. Featuring an optimized Hybrid Core Architecture, the Core i7-14700F powers demanding applications and games with eight 2.1 GHz Performance-cores, while the 12 low-voltage Efficient-cores handle background tasks for smooth multitasking. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time.
With 33MB of cache and a 5.4 GHz Turbo Boost Max 3.0 frequency, this processor is made to handle intense workloads. The Core i7-14700F also supports PCI Express 5.0 and up to 192GB of dual-channel DDR5 ECC memory at 5600 MHz. The Core i7-14700F does not include integrated graphics, meaning that users will need to purchase a separate dedicated graphics card. A Laminar RM1 cooler is included.
Hybrid Core Design
Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks such as streaming video, playing music, and encoding media are handled by the processor's Efficient-cores.
Intel Thread Director
The Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 28 threads are assigned to the right core at the right time.
PCIe 4.0 & 5.0
This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
General
| Brand | Intel |
|---|---|
| Processor Family | Intel Core i7 (14th Gen) |
| Model | i7-14700F |
| Part Number | BX8071514700F |
| Microarchitecture | Raptor Lake Refresh |
| Process Technology | Intel 7 (7 nm) |
| Socket | FCLGA1700 |
| Compatible Chipsets | Intel 700 Series, Intel 600 Series |
| Scalability | 1S Only |
| Included Cooler | Intel Laminar RM1 |
Performance
| Total Cores | 20 (8 Performance-cores + 12 Efficient-cores) |
|---|---|
| Total Threads | 28 |
| Base Clock Speed (P-core) | 2.1 GHz |
| Base Clock Speed (E-core) | 1.5 GHz |
| Max Turbo Frequency (P-core) | 5.4 GHz |
| Max Turbo Frequency (E-core) | 4.2 GHz |
| L2 Cache | 28 MB |
| L3 Cache (Intel Smart Cache) | 33 MB |
| Instruction Set | 64-bit (Intel 64, SSE4.1, SSE4.2, AVX2) |
Power
| Processor Base Power (TDP) | 65 W |
|---|---|
| Maximum Turbo Power | 219 W |
Memory & I/O
| Max Memory Capacity | 192 GB |
|---|---|
| Memory Type | DDR5 (up to 5600 MT/s) / DDR4 (up to 3200 MT/s) |
| Memory Channels | Dual-Channel |
| ECC Memory Support | Yes |
| Max Memory Bandwidth | 89.6 GB/s |
| PCIe Version | PCIe 5.0 and PCIe 4.0 |
| Max PCIe Lanes | 20 (16x PCIe 5.0 + 4x PCIe 4.0) |
