MSI MAG FORGE M110R AIRFLOW Mini Tower PC Case
MSI
MSI MAG FORGE M110R AIRFLOW Mini Tower PC Case
The MSI MAG FORGE M110R AIRFLOW is a compact mini tower case designed for PC DIY builders working with micro-ATX and mini-ITX motherboards. It ships with four pre-installed ARGB fans and a control board supporting up to six fans, solving the challenge of building a visually striking compact system without adding separate RGB controllers. The tempered glass window and mesh front panel let you showcase your components while maintaining effective airflow.
Why this product
Four pre-installed ARGB fans with 26 modes
It comes ready to light up with three 120 mm front fans and one rear fan, all controllable via a single LED button to cycle through 26 built-in effects.
1-to-6 ARGB control board included
The pre-installed board lets you connect up to six ARGB fans total and control them all from one switch, eliminating the need for a separate RGB hub.
Mesh front panel for optimized cooling
The mesh design maximizes airflow intake, supporting up to six total 120 mm fans across the case for effective thermal management.
3 mm tempered glass side panel
A durable viewing window showcases your build without obscuring airflow or light diffusion.
Flexible storage for drives
It supports one 3.5" drive, two 2.5" drives, and one shared 2.5"/3.5" mount, accommodating SSDs and HDDs in various configurations.
- Form factorMini Tower
- Motherboard supportMicro-ATX, Mini-ITX
- Pre-installed fans4 × 120 mm ARGB
- Max GPU length300 mm
- Max CPU cooler height160 mm
- Drive bays1× 3.5", 2× 2.5", 1× 2.5"/3.5"
- Dimensions388 × 200 × 423 mm
- Weight4.27 kg
- SKUMSI-7324
- EAN4711377386227
- Supports micro-ATX and mini-ITX motherboards only—full-size ATX boards will not fit.
- Fits GPUs up to 300 mm in length and CPU coolers up to 160 mm in height.
- Accepts standard ATX power supplies up to 180 mm long, or up to 300 mm if the 3.5" HDD tray is removed.
- Front and top support 120 or 240 mm radiators; rear supports 120 mm only.
- I/O includes 2× USB 2.0, 1× USB 5Gbps, audio out, and mic in on the front panel.
Best for
- Builders prioritizing RGB aesthetics and customization without complex wiring
- Compact SFF builds using micro-ATX or mini-ITX platforms
- Users wanting plug-and-play lighting that works immediately out of the box
- Systems combining SSDs and mechanical drives in a small footprint
Trade-offs
- Full-size ATX motherboard builds—this case does not support standard ATX form factors.
- High-end GPUs longer than 300 mm or large tower coolers taller than 160 mm.
- Builds requiring more than four storage drives, as it supports a maximum of four bay positions.
- Custom water-cooling loops exceeding 240 mm radiator dimensions on the front or top.
Built on the spirit of the MAG Series, the MAG FORGE M110R AIRFLOW is a compact and sturdy mini tower designed for PC DIY builders. It supports micro-ATX and mini-ITX motherboards, providing optimized compatibility for compact builds.
The MAG FORGE M110R AIRFLOW is a compact, durable mini tower with four pre-installed ARGB fans, optimized airflow and 1-to-6 ARGB control board, delivering powerful airflow and effortless customization for PC DIY builders.
Addressable RGB SHOWROOM
The MAG FORGE M110R AIRFLOW comes with 4 pre-installed ARGB fans (3 at the front and 1 at the rear), featuring 26 built-in lighting modes controlled via an LED switch button.
OPTIMIZED AIRFLOW
The MAG FORGE M110R AIRFLOW is equipped with a mesh on its front panel to provide optimal airflow for system cooling.
Tempered Glass Window
The MAG FORGE M110R AIRFLOW reveals your gaming components with a 3 mm tempered glass window that is durable and provides an excellent view of your system.
1-6 Fan Control Board
The fan control board supports up to six ARGB fans, controlled via an LED switch button. It provides stable power through a SATA connection and allows for easy customization.
STORAGE YOU NEED
Includes storage bays for two 2.5" drives, one 3.5" drive, and one 2.5"/3.5" drive mount.
General
| Brand | MSI |
|---|---|
| Model | MAG FORGE M110R AIRFLOW |
| Case type | Mini Tower |
Motherboard & compatibility
| Motherboard form factors | Micro-ATX, Mini-ITX |
|---|---|
| Maximum GPU length | 300 mm |
| Maximum CPU cooler height | 160 mm |
| Expansion slots | 4 |
Cooling & fans
| Pre-installed fans | Front: 3 × 120 mm ARGB, Rear: 1 × 120 mm ARGB |
|---|---|
| Maximum total fan support | Up to 6 × 120 mm |
| Front fan support | 3 × 120 mm |
| Top fan support | 2 × 120 mm |
| Rear fan support | 1 × 120 mm |
| Radiator support | Front: 120/240 mm, Top: 120/240 mm, Rear: 120 mm |
RGB & control
| ARGB control board | 1-to-6 ARGB (pre-installed) |
|---|---|
| Lighting modes | 26 built-in effects |
| Control method | LED switch button |
Storage
| 3.5" drive bays | 1 |
|---|---|
| 2.5" drive bays | 2 |
| Shared 2.5"/3.5" mount | 1 |
Power & I/O
| Power supply form factor | ATX |
|---|---|
| Maximum PSU length | 180 mm (or 300 mm without 3.5" HDD tray) |
| Front I/O ports | 1× Audio Out, 1× Mic In, 2× USB 2.0 Type-A, 1× USB 5Gbps Type-A |
| Front panel buttons | Power, Reset, LED Switch |
Physical
| Dimensions (D × W × H) | 388 × 200 × 423 mm |
|---|---|
| Side panel | 3 mm tempered glass |
| Front panel | Mesh |
| Net weight | 4.27 kg |
