TP-Link TL-SG2210MP 10-Port Gigabit Smart PoE+ Switch 150W
TP-Link
TP-Link TL-SG2210MP 10-Port Gigabit Smart PoE+ Switch 150W
The TP-Link TL-SG2210MP is a 10-port managed switch designed for small-to-medium business networks running surveillance, VoIP, and wireless access points. It delivers 150W of PoE+ power across eight ports to run compatible devices remotely, with cloud management and Layer 2 security built in.
Why this product
150W PoE+ powers eight devices at once
Each of the eight PoE+ ports supplies up to 30W, enough to run IP cameras, access points, and phones without separate power supplies.
20 Gbps switching fabric handles voice and video
The 14.88 Mpps forwarding rate and Layer 2/3/4 QoS keep video streams smooth and calls clear, even under load.
Cloud and app management from anywhere
Omada SDN integration lets you monitor and configure the switch via smartphone, tablet or web browser without being on-site.
Built-in Layer 2 security
IP-MAC-Port Binding, access control lists, port security, DHCP snooping, and 802.1X authentication defend against common network attacks.
- PoE+ ports8, up to 30W each
- Total PoE budget150W
- Switching capacity20 Gbps
- Forwarding rate14.88 Mpps
- Uplink ports2× SFP (100/1000 Mbps)
- Power consumption173.90W max
- SKUTPL-1284
- EAN6935364030681
- Runs standard Gigabit Ethernet devices: computers, printers, NAS drives, and other RJ45-equipped gear on the eight main ports.
- Supplies PoE+ (802.3at/af) to IP cameras, wireless access points, IP phones, and other PoE-enabled equipment up to 30W per port.
- Accepts fiber uplinks on two 100/1000 Mbps SFP slots for long-distance or high-interference connections.
- Requires 100–240V AC power and produces 173.90W at maximum load; verify your mains supply and circuit breaker capacity.
- Does not supply power over non-PoE ports; the two SFP slots are uplink-only and carry no PoE.
Best for
- Small offices and retail sites running three to eight IP cameras or access points
- Mixed wired and wireless networks needing centralized PoE and cloud visibility
- Teams that manage multiple sites and need remote provisioning and monitoring
- Networks requiring Layer 2 security controls and VLAN segmentation
Trade-offs
- Large deployments: only ten total ports (eight PoE, two SFP) limit scale; larger sites need stacked or modular switches.
- Devices drawing more than 30W: high-powered PTZ cameras and industrial equipment need external PoE injectors or separate power.
- Layer 3 routing at scale: static router support is limited to 32 entries; core network backbone needs an L3-capable device.
- Networks without internet or Omada infrastructure: cloud management is optional, but local-only monitoring requires manual web interface access.
Expand your office or business network capacity to handle a multitude of applications with the JetStream TL-SG2210MP 10-Port Gigabit Smart Switch with 8-Port PoE+ from TP-Link.
This managed switch features eight PoE+ compliant Gigabit Ethernet ports, delivering up to 30W per port with a 150W budget to operate compatible devices such as IP security cameras, VoIP phones, and wireless access points. Two Gigabit SFP ports are also available for fiber uplink connections.
With its 20 Gb/s switching capacity and 14.9 Mpps forwarding rate, the TL-SG2210MP provides smooth data transfers that are optimized for voice and video applications.
Your data is protected by a host of Layer 2 security features, including an Access Control List (ACL) and VLAN support. Protect your network from attacks and intrusions with IP-MAC-Port Binding, Access Control List, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
Use the Omada Software Defined Networking platform to monitor your connected network devices and manage them remotely from the cloud or with the Omada app. Enjoy Zero-Touch Provisioning, Centralized Cloud Management, and Intelligent Monitoring. Configure, manage, and monitor your network devices from almost anywhere in the world using your smartphone or tablet.
This switch uses a single fan to help maintain optimal temperature and performance. With TP-Link's limited lifetime warranty and 24/7 technical support, you can work with confidence, knowing that you're backed by the best in the industry.
Networking
| Brand | TP-Link |
|---|---|
| Standards | IEEE 802.3i, 802.3u, 802.3ab, 802.3z, 802.3ad, 802.3x, 802.3af, 802.3at, 802.3az, 802.1d, 802.1s, 802.1w, 802.1q, 802.1x, 802.1p |
| PoE standard | 802.3af/at |
| MAC address table | 8K |
| Static routers | 32 (IPv4, IPv6) |
Performance
| Switching capacity | 20 Gbps |
|---|---|
| Packet forwarding rate | 14.88 Mpps |
| Packet buffer | 4.1 Mbit |
| Jumbo frame | 9 KB |
| Transmission method | Store and Forward |
| DRAM | 256 MB |
| Flash | 32 MB |
Ports & power
| Gigabit Ethernet ports | 8× 10/100/1000 Mbps RJ45, all PoE+ capable |
|---|---|
| SFP uplink slots | 2× 100/1000 Mbps |
| PoE+ ports | 8, up to 30W per port |
| PoE power budget | 150W |
| Power supply | 100–240V AC, 50/60Hz |
| Max power consumption | 173.90W |
Physical
| Mounting | Rack-mountable / Desktop |
|---|---|
| Warranty | Limited Lifetime Protection |
