Ubiquiti ES-24-250W EdgeSwitch 24-Port PoE+ Gigabit Switch
Ubiquiti
Ubiquiti ES-24-250W EdgeSwitch 24-Port PoE+ Gigabit Switch
The Ubiquiti ES-24-250W EdgeSwitch is a fully managed Layer 2/3 PoE+ Gigabit switch designed for growing networks that need robust performance and intelligent switching. It combines 24 Gigabit ports with PoE+ power delivery, SFP uplinks, and advanced routing capability in a compact rack-mountable form factor.
Why this product
24 PoE+ ports in 1U
Power and connect 24 devices over standard Ethernet cable with IEEE 802.3at/af PoE+ (up to 34.2W per port) or 24V Passive PoE, eliminating separate power runs.
52 Gbps switching capacity
Non-blocking 26 Gbps throughput and 38.69 Mpps forwarding rate deliver wire-speed performance across all ports simultaneously.
Layer 2/3 routing
Full Layer 2 switching features plus Layer 3 routing capability mean it can handle both core switching and routing tasks.
SFP uplinks
Two SFP ports support fibre or direct copper connections for backbone links and long-distance runs.
- Ports(24) Gigabit RJ45 + (2) SFP + (1) Serial console
- Switching capacity52 Gbps
- Non-blocking throughput26 Gbps
- Power budget250W (max PoE+ 34.2W per port)
- Form factor1U rackmount
- Weight4.7 kg
- SKUUBI-1279
- EAN810354022241
- Fits standard 19-inch racks as a 1U unit with rackmount brackets.
- Powers from 100-240VAC, 50-60 Hz — standard worldwide mains supply.
- Delivers PoE+ to devices rated for IEEE 802.3at/af or 24V Passive PoE.
- Maximum 250W total budget across all ports — plan PoE load carefully if powering many high-draw devices simultaneously.
Best for
- Small offices and branch networks needing to power wireless APs, IP cameras and VoIP phones from one unit
- Rack-mounted deployments where space and power efficiency matter
- Networks requiring both Layer 2 switching and Layer 3 routing without separate appliances
Trade-offs
- Very large PoE deployments: 250W total budget limits the number of simultaneous high-power PoE devices.
- Multi-gigabit endpoints: Ports are Gigabit only (1 Gbps); no 10G or faster options.
- Passive PoE injectors or legacy 48V systems: Supports only IEEE 802.3at/af PoE+ and 24V Passive PoE.
Advanced Switching Technology for the Masses.
Build and expand your network with Ubiquiti Networks® EdgeSwitch™, part of the EdgeMAX® line of products.
The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks.
The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.
Networking
| Brand | Ubiquiti |
|---|---|
| Model | ES-24-250W |
| Standard | Layer 2/3 managed switch |
| PoE standard | IEEE 802.3at/af PoE+ and 24V Passive PoE |
Performance
| Switching capacity | 52 Gbps |
|---|---|
| Non-blocking throughput | 26 Gbps |
| Forwarding rate | 38.69 Mpps |
Ports & power
| Gigabit RJ45 ports | (24) |
|---|---|
| SFP ports | (2) |
| Serial console port | (1) |
| Max PoE+ per port | 34.2W |
| Max Passive PoE per port | 17W |
| Maximum power consumption | 250W |
| Power input | 100-240VAC, 50-60 Hz |
Physical
| Mounting | Rack-mountable, 1U |
|---|---|
| Dimensions | 485 x 43.7 x 285.4 mm |
| Weight | 4.7 kg |
