Ubiquiti POE-24-12W-G-WH 24V 12W Gigabit Passive PoE Injector
Ubiquiti
Ubiquiti POE-24-12W-G-WH 24V 12W Gigabit Passive PoE Injector
The Ubiquiti POE-24-12W-G-WH is a 24V passive PoE injector designed to power Ubiquiti networking devices over standard Ethernet cable. It combines surge and clamping protection with a Gigabit LAN port, making it suitable for outdoor installations and remote locations where equipment protection is essential.
Why this product
Surge and clamping protection built in
It protects against electrostatic discharge with difference and common mode surge protection, plus 60V power clamping and 11V data clamping to safeguard connected devices.
Gigabit Ethernet passthrough
It maintains full data rates while injecting power on pins 4, 5 and 3, 6, 7, 8, letting devices communicate and receive power simultaneously.
Wall-mountable design
It can be mounted directly to a wall or pole using optional brackets, keeping installation tidy and keeping cable runs short in outdoor deployments.
Remote reset and local button
It includes both a physical reset button and remote reset capability, allowing you to restart connected equipment without climbing to the installation site.
Works with most Ubiquiti gear
It powers airMAX, EdgeMAX, UniFi APs, UniFi Protect, airFiber, U Fiber, and mFi devices, plus it bridges airGateway connections to Wi-Fi.
- Output Power24V DC @ 0.5A (12W)
- Input Voltage100–240V AC, 50/60Hz
- Gigabit EthernetYes
- Surge Protection1500A (8/20 μs) power; 36A (10/1000 μs) data
- Dimensions87 x 44 x 29 mm
- Weight99 g
- ColorWhite
- SKUUBI-1136
- EAN810354025983
- Powers all Ubiquiti airMAX, EdgeMAX, UniFi AP, UniFi Protect, airFiber, U Fiber, mFi and LED devices rated for 24V input.
- Works with airGateway to bridge airMAX wireless links to Wi-Fi at customer locations.
- Requires Ubiquiti TOUGHCable for optimal earth grounding and surge protection; standard cables will still carry power and data but lack the additional ground path.
- Does not power devices designed for 15V input; use POE-15-12W for those applications.
- Does not support devices requiring more than 12W (0.5A at 24V); use higher-wattage models for power-hungry equipment.
Best for
- Outdoor and remote installations where equipment is exposed to lightning and surge risk
- Deployments using Ubiquiti's airMAX wireless backbone or EdgeMAX routing platforms
- Wall or pole-mounted setups where space is tight and cable runs need to be minimised
- Sites requiring remote management; the reset capability eliminates service calls for simple reboots
Trade-offs
- High-power devices: supplies only 12W; any equipment needing more than 0.5A at 24V requires a higher-wattage injector.
- Non-Ubiquiti or generic PoE devices: compatibility is optimised for Ubiquiti product lines and may not work reliably with third-party equipment.
- Environments above 40°C ambient temperature: the unit is rated only to 0–40°C operating temperature, limiting use in very hot climates.
- Installations without surge protection at the source: while it provides downstream protection, it does not replace surge protection on the AC mains inlet.
Ubiquiti 24 V DC PoE Adapters providing a variety of features to help protect your PoE devices.
PoE Adapters are highly reliable, and when used with Ubiquiti TOUGHCable™, they provide earth grounding and surge protection to help protect against electrostatic discharge (ESD) events.
The 24V, 0.5A models, POE-24-12W and POE-24-12W-G, are wall-mountable using the optional wall-mount brackets.
The 15V, 0.8A and 24V, 0.5A models, POE-15-12W, POE-24-12W and POE-24-12W-G, work with the airGateway™ to bridge airMAX® connections to Wi-Fi at customer locations.
Ubiquiti PoE Adapters provide a variety of features to help protect your PoE devices:
- Surge protection
- Clamping protection
- Maximum surge discharge
- Peak pulse current
- AC cable with earth ground
The PoE Adapters are compatible with most Ubiquiti PoE devices, including:
- airFiber®
- airMAX®
- EdgeMAX®
- mFi®
- UniFi® AP
- UniFi Protect / airVision®
- UniFi LED
- U Fiber
General
| Brand | Ubiquiti |
|---|---|
| Model | POE-24-12W-G-WH |
| Color | White |
Power Output
| Output Voltage | 24V DC |
|---|---|
| Output Current | 0.5A |
| Maximum Power | 12W |
| Efficiency | 82.96% |
| Line Regulation | ≤ 3% |
| Load Regulation | ≤ 5% |
Power Input & Connectors
| Input Voltage Range | 100–240V AC |
|---|---|
| Input Frequency | 50/60Hz |
| Input Current | 0.3A @ 120V AC, 0.2A @ 240V AC |
| Inrush Current | <30A peak @ 120V AC, <60A peak @ 230V AC |
| AC Connector | IEC-320 C6 |
| Power Cable | Included |
| Switching Frequency | 50 kHz |
Data & PoE
| Networking Interface | RJ45 |
|---|---|
| Data In / PoE | RJ45 shielded socket |
| Gigabit LAN Port | Yes |
| 2-pair Powering | Pins 4, 5 (+) and Pins 3, 6, 7, 8 (-) |
Protection & Management
| Surge Protection | Difference and common mode |
|---|---|
| Clamping Protection | 11V data, 60V power |
| Max. Surge Discharge | 1500A (8/20 μs) power |
| Peak Pulse Current | 36A (10/1000 μs) data |
| Shunt Capacitance | <5 pF data |
| Response Time | <1 ns |
| Reset Button | Yes |
| Remote Reset Capability | Yes |
Environmental
| Operating Temperature | 0 to 40°C (32 to 104°F) |
|---|---|
| Storage Temperature | -30 to 70°C (-22 to 158°F) |
| Operating Humidity | 35 to 95% noncondensing |
| Dimensions | 87 x 44 x 29 mm (3.4 x 1.7 x 1.1") |
| Weight | 99 g (3.5 oz) |
| Certifications | CE, FCC, IC, UL |
