Ubiquiti USW-24-POE UniFi 24-Port PoE+ Gigabit Switch
Ubiquiti
Ubiquiti USW-24-POE UniFi 24-Port PoE+ Gigabit Switch
The Ubiquiti USW-24-POE UniFi is a 24-port managed Gigabit switch designed for small office and enterprise networks that need both wired connectivity and power delivery to networked devices. It combines 16 PoE+ ports with 8 standard Gigabit ports and dual SFP fiber uplinks in a compact fanless chassis, managed through Ubiquiti's UniFi controller software.
Why this product
16 PoE+ ports deliver power and data
Sixteen ports support 802.3at PoE+, letting you power cameras, access points, phones and other devices without separate power supplies. Total PoE availability is 95W across all ports.
Fanless design runs silent
No moving parts means no cooling noise, making it suitable for offices and other quiet spaces. It dissipates heat passively in a compact 1U form factor.
Fiber uplinks for longer distances
Two 1G SFP ports provide Gigabit fiber connectivity, letting you extend your network to distant buildings or add redundant backbone links without copper distance limits.
52 Gbps switching capacity
The switch handles up to 52 Gbps of simultaneous traffic, with a 26 Gbps non-blocking throughput and 39 Mpps forwarding rate for smooth network operation under load.
UniFi controller management
Configure and monitor the switch through Ubiquiti's UniFi Network Controller software, which runs on-premises or in the cloud, with mobile app support included.
- Ports24 × 1GbE (16 PoE+), 2 × 1G SFP
- PoE budget95W total
- Switching capacity52 Gbps
- Form factor1U rackmount
- CoolingFanless
- Power draw (no PoE output)25W
- Power draw (with PoE output)120W
- SKUUBI-1332
- EAN817882028554
- Works with any 802.3af or 802.3at PoE-enabled device: IP cameras, UniFi access points, VoIP phones, access controls and other standard PoE equipment.
- Integrates with Ubiquiti UniFi ecosystem; managed through UniFi Network Controller software (cloud or self-hosted) and the UniFi mobile app.
- Fits standard 19" networking racks as a 1U unit; rackmount brackets are included.
- Connects to standard Gigabit Ethernet (RJ45) devices and single-mode or multimode 1G SFP modules for fiber links.
- Requires UniFi Network Controller (separate software or appliance) for advanced management; basic layer 2 switching works without it, but full feature access needs the controller.
Best for
- Small offices and remote sites needing to power and connect cameras, access points and phones from one switch without running extra power cables.
- Networks requiring silent, fanless operation in noise-sensitive spaces such as offices, conference rooms or education facilities.
- Ubiquiti UniFi deployments where centralized management through the UniFi Controller ecosystem is already in place.
- Deployments requiring fiber backbone links or uplinks to distant switches using the dual SFP ports for longer runs.
Trade-offs
- High-density PoE environments. At 95W total PoE budget, it cannot power 16 devices simultaneously if they each draw close to their maximum. Plan around this limit when connecting many power-hungry cameras or access points.
- Networks needing more than 24 ports. This switch has a fixed port count; larger networks will need additional switches or a higher-port-count model.
- Environments without UniFi infrastructure. While it functions as a basic unmanaged switch, the USW-24-POE's advanced features (VLANs, ACLs, port mirroring, aggregation) require UniFi Network Controller software.
- 10 Gigabit or higher-speed requirements. All ports are Gigabit (1G); it does not support 10GbE connections.
The USW-24-POE is a configurable Gigabit Layer 2 switch with twenty-four Gigabit Ethernet ports including sixteen auto-sensing 802.3at PoE+ ports, and two SFP ports.
It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network.
The USW-24-POE features a 1.3" touch LCM to provide status information.
With a depth of 7.9", the compact fanless design can be easily installed in a SOHO rack cabinet.
Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-24-POE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port.
Networking
| Brand | Ubiquiti |
|---|---|
| Standard | 802.3at PoE+ |
| Layer | Layer 2 managed switch |
| Supported VLANs | 1,000 |
| MAC address table size | 8,000 |
| Access lists (IPv4) | 128 |
| Access lists (MAC) | 128 |
| Layer 2 features | LACP port aggregation, STP & RSTP, IGMP snooping, 802.1X control, MAC-based ACLs, device isolation |
Ports & power
| Ports | 24 × Gigabit RJ45 (16 with PoE+, 8 standard) + 2 × 1G SFP |
|---|---|
| Total PoE availability | 95W |
| Power supply | AC/DC internal, 120W |
| Input voltage | 100–240VAC, 50/60 Hz |
Performance
| Switching capacity | 52 Gbps |
|---|---|
| Non-blocking throughput | 26 Gbps |
| Forwarding rate | 39 Mpps |
| Packet buffer | 0.5 MB |
Physical
| Mounting | 1U rackmount (brackets included) |
|---|---|
| Dimensions | 442 × 200 × 44 mm (17.4 × 7.9 × 1.7 in) |
| Weight | 3.00 kg (6.61 lb); 3.09 kg (6.81 lb) with brackets |
| Cooling | Fanless |
| ESD/EMP protection | Air: ±16 kV, Contact: ±12 kV |
| Touch display | 1.3" LCM for status information |
