Ubiquiti USW-Aggregation UniFi 8-Port 10G SFP+ Switch
Ubiquiti
Ubiquiti USW-Aggregation UniFi 8-Port 10G SFP+ Switch
The Ubiquiti USW-Aggregation UniFi is an 8-port, Layer 2 switch built for 10G SFP+ connections and link aggregation in UniFi deployments. It suits network administrators and integrators who need to consolidate high-bandwidth traffic between core switches, access points, and storage systems. The compact 1U form factor and fanless design make it suitable for equipment racks where noise and space are constraints.
Why this product
160 Gbps switching capacity
Eight 10G SFP+ ports support full non-blocking throughput of 80 Gbps, handling simultaneous traffic across all ports without bottlenecks.
Link aggregation for redundancy
Layer 2 switching with VLAN support (1,000 VLANs) and a 16,000-entry MAC table allow you to bond ports together for higher bandwidth and failover protection in UniFi networks.
Touchscreen management
Built-in 1.3" LCM color touchscreen with AR-assisted switch management eliminates the need for a separate console or network connection during initial setup.
Compact, fanless, rackmount
1U form factor at just 4.7" deep, fanless operation, and included rack-mount kit fit dense equipment rooms and silent installations.
Copper module support
Internal 36W AC/DC supply supports up to four copper Ethernet UF-RJ45-10G modules (sold separately) for mixed SFP+ and RJ45 deployments.
- Ports8× 10G SFP+
- Switching capacity160 Gbps
- Non-blocking throughput80 Gbps
- Power consumption30W maximum
- Form factor1U rackmount
- Warranty2 years
- SKUUBI-1339
- EAN810010074331
- UniFi Network Application version 5.14.12 and later for full management integration.
- Standard SFP+ transceivers: supports both multimode (UACC-OM-MM-10G) and single-mode (UACC-OM-SM-10G) fiber modules in all eight ports.
- Rack-mount installation: 1U height, standard EIA 19" rack rails included.
- Universal AC input 100–240V, 50/60 Hz supports global power standards.
- Copper modules (UACC-CM-RJ45-10G or UACC-CM-RJ45-MG) supported in four ports maximum; SFP+ fiber remains in remaining ports.
Best for
- Core and distribution layer aggregation in UniFi networks
- High-speed interconnect between access points, switches, and storage
- Equipment racks requiring silent, fanless operation
- Small to medium deployments needing Layer 2 switching with link aggregation
- Deployments mixing fiber and copper connectivity
Trade-offs
- Layer 3 routing: This is a Layer 2 switch; it does not route IP traffic or perform inter-VLAN routing.
- PoE delivery: No PoE or PoE+ power output; use a separate PoE injector or switch for powered devices.
- All-copper environments: Supports only four copper RJ45 modules; fiber SFP+ is required for the remaining ports.
- Large-scale enterprise deployments: Maximum 1,000 VLANs and 16,000 MAC addresses suit SMB and mid-market networks, not carrier-grade or large campus switching.
USW-Aggregation is a managed Layer 2 switch with eight 10G SFP+ ports, offering link aggregation for higher capacity and increased availability.
USW-Aggregation features Layer 2 capabilities and supports high-bandwidth links, making it ideal for aggregation switching to any UniFi solution that deploys various interconnect topologies.
Built-in 36W AC/DC power supply can support copper Ethernet UF-RJ45-10G modules (sold separately) in all eight ports.
General
| Brand | Ubiquiti |
|---|
Networking
| Standard | Layer 2 |
|---|---|
| Switching capacity | 160 Gbps |
| Non-blocking throughput | 80 Gbps |
| Forwarding rate | 119.04 Mpps |
| Supported VLANs | 1,000 |
| MAC address table | 16,000 entries |
| Packet buffer | 1.5 MB |
Ports & power
| Ports | (8) 10G SFP+ (10G/1G capable) |
|---|---|
| SFP+ module support | 8× multimode fiber, 8× single-mode fiber, 4× copper RJ45 |
| Power input | Universal 100–240V AC, 50/60 Hz |
| Power supply | Internal AC/DC, 36W |
| Max. power consumption | 30W |
| Management interface | Ethernet in-band |
| Display | 1.3" LCM color touchscreen |
Physical
| Form factor | 1U rackmount |
|---|---|
| Dimensions | 442 × 120 × 43.7 mm (17.4 × 4.7 × 1.7") |
| Weight | 2.6 kg (5.8 lb) without brackets; 2.7 kg (6 lb) with brackets |
| Enclosure | SGCC steel |
| Mounting | 19" rack rails included |
| Operating temperature | −5 to 40°C (23 to 104°F) |
| Operating humidity | 10 to 90% noncondensing |
| ESD protection | ±16 kV air, ±12 kV contact |
Support
| Warranty | 2 years |
|---|---|
| Certifications | CE, FCC, IC |
| UniFi Network Application | Version 5.14.12 and later |
