Ubiquiti USW-PRO-48-POE UniFi Pro 48 PoE Switch 600W
The Ubiquiti USW-PRO-48-POE UniFi Pro 48 PoE Switch is a fully managed Layer 3 switch designed for enterprise networks that need high-density PoE delivery across multiple device types. It combines 48 Gigabit ports with 4 x 10G SFP+ uplinks and 600W of PoE power to support IP cameras, wireless access points, and other networked devices from a single rack unit.
Why this product
600W PoE power across 48 ports
Deliver up to PoE++ (60W per port) on ports 41-48 and PoE+ on ports 1-40, enough to run dozens of powered devices without external injectors.
Layer 3 routing and VLAN support
Inter-VLAN routing, static routing, and DHCP server built in. Supports up to 1,000 VLANs for segmentation and access control on the same physical switch.
176 Gbps switching fabric
Non-blocking 88 Gbps throughput with 131 Mpps forwarding rate handles traffic from dozens of connected devices without congestion.
1.3-inch touchscreen management
Quick diagnostics and switch state visibility via integrated display. Full configuration available through UniFi Network web app and mobile app from anywhere.
Redundant power input
Supports both AC input (100-240V) and DC backup via optional USP RPS for uninterrupted operation during power loss.
- Ports48 × Gigabit RJ45, 4 × 10G SFP+
- PoE supply600W total (PoE+ on ports 1–40, PoE++ on ports 41–48)
- Switching capacity176 Gbps
- Throughput88 Gbps non-blocking
- Form factor1U rack mount
- Dimensions442 × 400 × 44 mm
- Weight6.25 kg
- Power consumption60W (excluding PoE), 660W (including PoE output)
- SKUUBI-1166
- EAN817882027656
- Works with any IP device supporting standard Ethernet RJ45 or 10G SFP+ connectivity.
- Integrates with the UniFi Network ecosystem for unified management alongside access points, gateways, and other UniFi hardware.
- Supports PoE+ (30W) and PoE++ (60W) standards for powering modern IP cameras, access points, and networked devices.
- Operates in data centre and enterprise rack environments; requires standard 19-inch rack and 1U of vertical space.
- DC power backup via USP RPS requires separate purchase and compatible DC power supply.
Best for
- Large deployments of PoE devices
- Network segmentation and routing
- High-throughput data centre or campus backbones
- Unified infrastructure management
Trade-offs
- Small office or single-building deployments
- Non-UniFi networks
- Budget-constrained projects
- Environments without managed network experience
Build and expand your network with the UniFi Switch, part of the Ubiquiti UniFi Enterprise System.
The Switch Pro 48 PoE (USW Pro 48 PoE) is a fully managed switch with (40) GbE, 802.3at PoE+ RJ45 ports, (8) GbE, 802.3bt PoE++ RJ45 ports, and (4) 10G SFP+ ports. The USW Pro 48 PoE combines a rich set of Layer 2 features with advanced Layer 3 tools including inter-VLAN routing, static routing, and a DHCP server. The USW Pro 48 PoE is the ideal access layer switch for any UniFi system. It combines up to 600W of PoE power with SmartPower RPS (USP RPS) power redundancy. The switch can also be monitored and configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
The UniFi Switch PRO 48 PoE features an 1.3" touch LCM and integrated fans for quiet cooling. The LCM provides current switch states and the necessary information you need for quick diagnosis.
Networking
| Brand | Ubiquiti |
|---|---|
| Standard | 802.3af/at (PoE+), 802.3bt (PoE++), 10G Ethernet SFP+ |
| Layer 3 features | DHCP Server, DHCP Relay, Inter-VLAN Routing, Static Routing |
| VLANs supported | 1,000 |
| IPv4 static routes | 256 |
| MAC address table size | 16,000 |
| Access lists (IPv4) | 128 |
| Access lists (MAC) | 128 |
Performance
| Switching capacity | 176 Gbps |
|---|---|
| Non-blocking throughput | 88 Gbps |
| Forwarding rate | 131 Mpps |
| Packet buffer | 4 MB |
Ports & power
| Ports | 48 × 10/100/1000 RJ45 Ethernet; 4 × 1/10G SFP+ Ethernet |
|---|---|
| PoE supply | 600W total |
| PoE+ ports (1–40) | Up to 30W per port, IEEE 802.3at |
| PoE++ ports (41–48) | Up to 60W per port, IEEE 802.3bt |
| Power input (AC) | 100–240V, 50–60 Hz |
| Power input (DC) | 52VDC 11.54A or 11.5VDC 5.22A (USP RPS) |
| Max. power consumption | 60W (excluding PoE output), 660W (including PoE output) |
| Redundancy | DC power backup via USP RPS |
Physical
| Mounting | Rack mount (1U) |
|---|---|
| Dimensions | 442 × 400 × 44 mm (17.4 × 15.7 × 1.7 in) |
| Weight | 6.25 kg (13.78 lb) |
| Operating temperature | -5 to 40°C |
| ESD/EMP protection | ±16 kV (air), ±12 kV (contact) |
| Touch display | 1.3-inch LCM colour touchscreen with AR management |
| LEDs | System status; RJ45 PoE/speed/link/activity; SFP+ link/activity |
| Cooling | Integrated fans (near-silent) |
